Parallel Autoclavable Fermenter Block System
The BioQuadX Glass Autoclavable Multiple Fermenter System is a complete, advanced fermentation setup specifically engineered for process development and optimization, helping to significantly reduce the time from product conception to market launch. This high-throughput system supports the simultaneous operation of 4 vessels, providing uniform control accuracy and effortless scalability. Each vessel enables independent regulation of critical parameters such as Agitation, Aeration, temperature, pH, DO, Foam/OD/ORP.
Unlike traditional incubator shakers and shake flasks, which offer only limited control over environmental conditions and often lead to inconsistent results, our BioQuadX system delivers real-time monitoring, precise parameter adjustment, and reproducible outcomes. This makes it an ideal choice for rapid strain screening, media optimization, and process intensification. Available in Basic or Premium models, the system can also be customized to meet specific research or development requirements, making it a versatile tool for modern biotechnology laboratories.
Technical Specifications:
| Type: | Autoclavable |
| Design Code: | ASME BPE-2019 |
| Temperature: | 0 to 130 °C |
| pH: | 2 to 14 |
| DO2: | 0-100% |
| MOC: | Borosilicate Glass & SS 316L |
| Automation Grade: | Basic & Fully Automatic |
| Surface Finish SS: | Inner surface 240 grit Finished & mirror polished Ra≤0.5µm and External 180 grit matt finish. |
Features:
- Top driven with mechanical seal and Rushton Turbine/Marine Impellers with removable baffles with precision rpm controlled with servo motor.
- For 0.1-1.5 vvm, ring/microspargers with gas mixing option, air/gas flow control through Rotameter & MFC with Inlet/Exhaust filters and condenser.
- Feeding ports (acid/ base/antifoam/nutrients) with inoculation Septum port (multiport injection system), Air Exhaust with cooling condenser, pH and DO sensor, Temperature sensor, sampling/harvest dip tube port, Redox port/Turbidity sensor.
- Cooling coil on top plate and heater at bottom.
- SS panel, color touch screen HMI, high speed plc, digital & analog i/o cards, relay output or transistor output with relays, tcp ip modbus communication, usb port, ethernet port
- Temperature control, pH control, do control, nutrient feeding, SCADA, exhaust gas monitoring, redox monitoring (orp)/turbidity monitoring (od), agitation control and aeration control
Controls:
- Automatic Temperature Control
- Automatic Agitation Control
- Automatic Aeration Control
- Automatic pH Control
- Automatic Foaming/ Redox Monitoring/ Turbidity Measurement
- Automatic Nutrient Feeding Control
- Aeration Control through rotameter/MFC
- Automatic DO Control (Cascade Control)
- Mobile Application
- SMS Alert Facility
- Control Panel – Independent / Combined
- Supervisory Control And Data Acquisition (SCADA)
